Diamax SRVB230 Cyclone Wheel Stock Removal Vacuum Brazed Medium 2x2
The Diamax SRVB230 Cyclone Wheel Stock Removal Vacuum Brazed Medium 2x2 is a professional-grade shaping and grinding tool engineered for fast, controlled material removal on natural and engineered stone surfaces. Designed to meet the demands of stone fabricators, contractors, and installation professionals, this high-performance wheel delivers aggressive cutting power while maintaining smooth operation and precision control.
Product Overview
Constructed using advanced vacuum-brazed diamond technology, the SRVB230 features diamonds permanently bonded to the tool body for maximum exposure and cutting efficiency. This manufacturing process enhances durability, heat resistance, and long-lasting performance, even under heavy-duty shop or job-site conditions. The vacuum-brazed design also helps maintain consistent cutting action throughout the life of the wheel.
The 2x2 medium grit configuration provides an ideal balance between aggressive stock removal and surface control. It is well-suited for shaping edges, refining profiles, removing excess material, and preparing surfaces prior to finer grinding or polishing stages. The wheel’s design promotes minimal vibration, allowing for improved operator comfort and greater accuracy during shaping applications.
Applications
Engineered for use on granite, marble, quartz, and engineered stone, the SRVB230 performs effectively in both fabrication shops and field installations. Its balanced construction supports steady operation when mounted on standard angle grinders or air polishers, making it a versatile addition to any stone professional’s toolkit.
Whether you are shaping sink cutouts, adjusting edge profiles, removing high spots, or performing corrective grinding, the Diamax SRVB230 Cyclone Vacuum Brazed Wheel provides reliable, efficient performance for demanding stock removal applications.
Key Features & Benefits
-
Vacuum-brazed diamond construction for durability and long life
-
2x2 medium grit for efficient, controlled stock removal
-
Designed for granite, marble, quartz, and engineered stone
-
Minimal vibration for smoother operation and better control
-
Ideal for shaping, edge refinement, and surface preparation
-
Compatible with angle grinders and air polishers
-
Professional-grade performance for shop and job-site use
The Diamax SRVB230 Cyclone Wheel delivers the strength, precision, and reliability professionals depend on for efficient stone shaping and finishing work.
Key Features
-
Vacuum-brazed diamond segments for strong adhesion and long life on tough stone materials.
-
Efficient stock removal — fast material removal and shaping after sink cut-outs or edge profiling.
-
5/8″-11 threaded connection for compatibility with many angle grinders and polishers.
-
Medium grit / coarse action suitable for aggressive stock removal tasks.
-
Designed to work wet only (water-fed) for optimal performance and reduced dust.
Specifications
Technical Details
| Feature | Detail |
|---|---|
| SKU / Model | SRVB230 |
| Wheel Size | 2″ × 2″ (approx. 50 mm × 50 mm) |
| Grit | Coarse / Medium (approx. #30) |
| Thread Size | 5/8″-11 |
| Max RPM | ~4,000 rpm (typical rating) |
| Use Type | Wet stock removal on stone |
| Materials | Granite, marble, engineered stone, ultra-compact |
Available Models
ITEM # – SIZE – GRIT – FITTING – MAX RPM
SRVB230
-
Size: 2″ x 2″
-
Grit: Coarse 30
-
Fitting: 5/8″-11 thread
-
Max RPM: 4,000
SRVB250
-
Size: 2″ x 2″
-
Grit: Medium 60
-
Fitting: 5/8″-11 thread
-
Max RPM: 3,000 – 4,000
SRVB2100
-
Size: 2″ x 2″
-
Grit: Fine 100
-
Fitting: 5/8″-11 thread
-
Max RPM: 3,000 – 4,000
SRVB2038
-
Size: 2″ x 3/8″
-
Grit: Coarse 30
-
Fitting: 5/8″-11 thread
-
Max RPM: 3,000 – 4,000
SRVB2034
-
Size: 2″ x 3/4″
-
Grit: Coarse 30
-
Fitting: 5/8″-11 thread
-
Max RPM: 3,000 – 4,000
SRVB1002
-
Size: 1″ x 2″
-
Grit: 30 / 40
-
Fitting: 5/8″-11 thread
-
Max RPM: 3,000 – 4,000
SRVB2001
-
Size: 2″ x 2″
-
Grit: 30 / 40
-
Fitting: 5/8″-11 thread
-
Max RPM: 3,000 – 4,000
