Zenesis ZLGW20U0406C Glass Tile Diamond Blade

Product Overview

The Zenesis ZLGW20U0406C is a 4-inch patterned diamond blade designed for precision cutting of glass, tempered glass, and hard porcelain tiles. It is intended for wet cutting on handheld grinders or small wet saws, delivering chip-free, smooth cuts and long-lasting performance. The ZENESIS™ Glass Tile Blades provide chip-free performance significantly beyond anything currently available on the market on all types and thicknesses of glass.

Professional Precision Cutting

The Zenesis ZLGW20U0406C is a premium 4-inch patterned diamond blade engineered specifically for precision cutting of glass, tempered glass, and hard porcelain tiles. Designed for professional fabricators, tile installers, and stone specialists, this blade delivers exceptionally smooth, chip-free cuts, making it ideal for delicate and intricate applications where edge integrity is critical.

Optimized for Wet Cutting

Optimized for wet cutting on handheld grinders or compact wet saws, the ZLGW20U0406C ensures superior control, minimal vibration, and long-lasting performance. Its unique ZENESIS™ patterned diamond technology maintains consistent diamond exposure across the blade surface, providing stable, reliable cutting speed and extended tool life.

Ideal for Precision Fabrication

This blade is especially suitable for applications requiring precision edge work, cutouts, and detailed shaping of fragile or brittle materials such as tempered glass panels and fine porcelain tiles.

Advanced Glass Tile Cutting Technology

With its advanced design, the ZENESIS™ Glass Tile Blade delivers performance that exceeds standard glass cutting tools, combining efficiency, safety, and professional-quality results. Lightweight yet robust, it is an essential tool for high-accuracy fabrication, custom installations, and on-site precision cutting tasks, enabling fabricators to achieve flawless edges with reduced material waste and superior finish quality.

Key Features

Chip-Free Cutting

Chip-Free Cutting — engineered to minimize chipping and cracking on glass and porcelain.

7.5 mm Diamond Segment Height

7.5 mm Diamond Segment Height — provides durability and extended cutting life.

Patterned Diamond Edge

Patterned Diamond Edge — ensures consistent, smooth cuts.

Reinforced Core

Reinforced Core — reduces blade flex and improves accuracy.

Wet Cutting Only

Wet Cutting Only — water cooling improves performance and blade life.

Compact Size

Compact Size — ideal for handheld grinders and small wet saws used in glass and tile work.

Additional Capabilities

Also provides smooth clean cuts on Hard Porcelain
Must be used wet
Cuts Glass

Specifications

Product Specifications Table

Feature | Details
SKU | ZLGW20U0406C
Blade Type | Diamond glass / glass tile cutting blade
Diameter | 4″ (≈100 mm)
Segment Height | 7.5 mm
Arbor Size | 7/8″-5/8″ + 20 mm adapter
Cutting Method | Wet cutting only
Primary Materials | Glass, tempered glass, hard porcelain tiles
Application | Handheld grinder or wet tile saw for glass and porcelain
Technology | Patterned diamond edge for chip reduction

Typical Use Cases

Glass Panel Cutting

Cutting glass panels and decorative glass

Tempered Glass Tile Cutting

Cutting tempered glass tiles

Hard Porcelain Tile Cutting

Smooth cutting of hard porcelain tiles

Precision Handheld Cutting

Handheld tools or wet saws where precision and chip-free edges are required

Part Numbers and Dimensions

ZLGW20U0406C

Part No. ZLGW20U0406C
Diameter 4”
Segment 7.5mm
Arbor Size 7/8″-5/8″+20mm

ZLGW20U4506C

Part No. ZLGW20U4506C
Diameter 4.5”
Segment 7.5mm
Arbor Size 7/8″-5/8″+20mm

ZLGW20U0706A

Part No. ZLGW20U0706A
Diameter 7”
Segment 7.5mm
Arbor Size 5/8″

ZLGW20U1006A

Part No. ZLGW20U1006A
Diameter 10”
Segment 7.5mm
Arbor Size 5/8″
